Features :
Input voltage : 3V -35V(Input voltage is less than 4V, the on-board voltage meter failure)
Input Current: Maximum input current of 8A
Output voltage : 3.5V -35V continuously adjustable
Output current: maximum output current of 5A
Conversion efficiency: up to 95% ( input voltage, current; output voltage and current impact of conversion efficiency )
On-board voltmeter range: 4~40V, error: +-0.1V
“IN
“light is input voltage measurement,” OUT “light is measuring the
output voltage and voltage meter feature can be turned off, when it is
not needed the uprooting of P3 jumper caps on the line
Size :6.7 (L)x 4.1(W)x0.6(H)cm
Input
voltageoutput voltage
output
currentoutput
power
efficiency
5.0V
12V
1A
12W
94.1%
5.0V
12V
2A
24W
93.1%
7.4V
12V
1A
12W
95.4%
7.4V
12V
2A
24W
94.8%
7.4V
18V
1A
18W
94.5%
7.4V
18V
2A
36W
94.2%
7.4V
18V
3A
54W
93.8%
12V
18V
1A
18W
96.1%
12V
18V
2A
36W
95.5%
12V
18V
3A
54W
94.3%
18V
24V
1A
24W
96.5%
18V
24V
2A
48W
96.2%
18V
24V
3A
72W
95.7%
24v
32v
3.5A
112W
96.4% -
Package
100% Brand New
1x DC-DC 100W 3-35V to 3.5-35V Boost Step-up Module Power Supply + LED Voltmeter
