Speedstar Speedo F/R 12 Turn

The SPEEDSTAR 2 is a moderately priced electronic speed
controller for entry-level racers.With motorlimits 12 turns, ABS brakes, adjustable traction control and
reverse control, the SPEEDSTAR 2 also for intermediate or advanced
drivers.Pre-installed for plug in and drive.

Touring 12T Features

• Proportional speedo with forward, ABS brake and reverse.

• LiPo mode for the new battery technology.

• Single-Button setup.

• External power switch for easy on/off-switching.

• High switching frequency for better control and more runtime.

• Handles motors down to 12 turns.

• Switchable ABS-brake system.

• Three power programs for different track conditions.

• Plug and Play – comes with motor, battery and radio connectors.

• Overtemperature protection system.

• Splash-water proof electronics.

Specification

Case Size: 35x27x17mm

Weight with wires: 49g

Input power NiCd & NiMH: 6-7 cells (7.2-8.4V)

Input power LiPo: 2 cells (7.4V)

Operating frequency: 1.0 kHz

B.E.C. Output Voltage: 5.0 V

B.E.C. Constant current: 1.0 A

On-Resistance: 0.0035 ohms

Motor Turns Limit: 12 turns

Acceleration time delays: 0.09, 0.16, 0.27 sec.

Specification

Selection: Speed Controller
Categories: Brushed speedo
Propulsion Technique: Brushed
Scale: 1/10
Cells: max. 2S / 7 NiMH
Voltage: max. 8,4V
Load Capacity: max. 12Turn
Dimension: 35mm x 27mm x 17mm (L x W x H)
Weight: 49g
Content: 1 pcs.
Suitable for:     NiMH|LiPo
BEC Voltage     5,0V / 1A
