Product description
Single cylinder , two-stroke engine with a capacity of 33cc . Small size and weight coupled with superb power , allow the full potential of aircraft grade 1.8.
Engine TP 33 is the ideal solution in models where the count performance while maintaining a small size as possible . But it does not end application engine TorqPro – due to low weight and moderate demand for fuel , it is also an interesting proposition for aircraft mock-up – large-size , noticeably lengthening the flight time . No need for a classic bed , an additional weight reduction and space savings .
Presented engine includes includes , among others, electronic ignition , muffler , spark plugs , gaskets , bolts and machined aluminum parts.
Technical specification
Displacement: 33cm³
Piston diameter : 36mm
The length of the piston stroke : 32.5mm
Speed range : 1100-9000 r / min
Power : 3.85 hp / 9000 rev / min
Motor weight : 974g
The mass damper : 180g
Weight of ignition : 107g
Total engine weight : 1230g
Recommended fuel : Volume mix gasoline with oil in a pile. 40: 1 ( Art) or 32 : 1 ( to reach )
Type Carburetor : Walbro
Elements of the set
TP 33cc engine with carburetor Walbro
The silencer mounted on the side
Feet , washers and screws to fix the engine
Gasket and screws to attach the silencer
Candle NGK CM – 6
Electronic ignition system
