BANDIT (#24054-4) SPECS
- Length: 413 mm
- Front Track: 250 mm
- Rear Track: 250 mm
- Weight: 1.36 kg
- Height (Overall): 178 mm
- Wheelbase: 286 mm
- Front Shock Length: Long
- Rear Shock Length: XX-Long
- Front Tires (Pre-Glued): Alias™ Ribbed 2.2″
- Rear Tires (Pre-Glued): Alias™ Step-Pin 2.2″
- Front Wheels: 2.2″ Mirror-Chrome (Tracer™)
- Rear Wheels: 2.2″ Mirror-Chrome (Tracer™)
- Electronic Speed Control: XL-5™ Electronic Speed Control
- Motor (Electric): Titan® 12T 550 (12-Turn 550)
- Steering Servo: #2056 High Torque Waterproof
- Transmitter: TQ 2.4GHz Radio
- Receiver: #6519 3-Channel Micro
- Gear Ratio (Internal): 2.72 (Final Drive: 10.17)
- Differential Type: Planetary Steel Gear
- Gear Pitch: 48-Pitch
- Transmission: Magnum 272™
- Steering: Bellcrank
- Chassis Type: Modified Tub
- Chassis Material: Fiber-Composite
- Top-Speed: 56+kmh**
- Skill Level: 1
- *Battery Tray Dimensions: 139 x 47.5 x 28 mm
- Required Items: NiMH or LiPo Battery, Charger, 4 “AA” Batteries (Transmitter)
*Battery expansion kit available (#3725X)
**With 7-cell battery and included optional 31-tooth pinion gear
XL-5 (WATERPROOF) ESC SPECIFICATIONS
- Input Voltage: 4-7 Cells NiMH, 2-Cell (2S) LiPo
- Case Size: 1.23″W x 2.18″D x 0.61″ H
- Weight: 2.44 Ounce
- Motor Limit: 15-turns** (540 Size)
- 12-turns** (550 Size)
- On Resistance Forward: 0.007 Ohms
- On Resistance Reverse: 0.014 Ohms
- Peak Current – Forward: 100A
- Peak Current – Reverse: 60A
- Braking Current: 60A
- Continuous Current: 14A
- BEC Voltage: 6.0 VDC
- BEC Current: 1A
- Power Wire: 14 Gauge / 5″
- Input Harness Wire: 26 Gauge / 9″
- Transistor Type: MOSFET
- PWM Frequency: 1600 Hz
- Low Voltage Detection (LVD): 2-Stage Indicators, Switchable (On or Off)
- Thermal Protection: Thermal Shutdown
- Single-Button Setup: Yes, Traxxas EZ-Set®
Profile Selection:
- Sport Mode: 100% Fwd, 100% brakes, 100% Rev
- Race Mode: 100% Fwd, 100% brakes, no Rev
- Training Mode:* 50% Fwd, 100% brakes, 50% Rev
*Patented
**Properly Geared
Car Type: Buggy
Delivered as: RTR (Ready-To-Run)
Drive: 2WD
Operating Mode: Electric
Scale: 1/10
Suitable For: Beginners
Length: 413 mm
Height: 178 mm
Weight: 1360 g
Width: 250 mm
ESC: Traxxas XL-5
Top Speed: 55km/h
Transmitter: Traxxas TQ 2-Channel
Motor Type: Brushed
Motor/Engine: Traxxas Titan 12T 550
Battery: Not Included
Water Proof: Yes
Needed To Complete: 2S LiPo or 7-cell NiMH with iD connector, 4 AA batteries for transmitter, iD Charger
