iFlight TITAN DC7 HD Frame

PRODUCT DESCRIPTION

The TITAN DC7 HD Frame perfect fits the amazing new DJI FPV system with boomerang arms, this quad makes flying FPV truly breathtaking.

Features:

– Popular Deadcat style configuration, No prop in View

– Optimized weight distribution: DJI unit and Stack centered

– Fits both 30.5x and 20x stacks

– Full 3K Carbon Fiber airframe with chamfered boomerang arm

– 333mm wheelbase, weight: 208.8g dry with TPU parts

Specifications:

– Weight: 208.8 (with TPU parts, and battery anti-slip pads)

– Wheelbase: 333mm

– Main body dimension: 330*223mm

– Bottom to top distance: 35mm

– Arm thickness: 6mm

– Bottom plate thickness: 3mm

– Top plate thickness: 2.5mm

– Camera plate thickness: 1.5mm( 2.5mm included TPU inserts)

– Mounting Holes: 30.5*30.5mm / 20*20mm

– Support camera size: 19*19mm 22*22mm

– Recommended motors: 22xx, 23xx

Package included:

-1 x TITAN DC7 HD Frame

-1 x Screw Bag

-1 x TPU Camera mount adapters

-4 x Arm guard/Motor mount

-1 x TPU DJI Air Unit Bracket Mount

-1 x TPU DJI Air Unit Antenna Mount

-1 x TPU bottom plate front protective mount

-1 x TPU bottom plate rear protective mount

-1 x Battery Anti-slip Mat

-2 x Battery Straps

NOTE: frame with TPU parts only, the DJI air unit, antenna, propellers, motors, flight stacks all do not include.
