Leopard 60A ESC for 1/10 Car 4370KV

Product description

A Leopard set consisting of a 60A speed controller, a 4370kV brushless motor and a programming card.

Technical data

Engine parameters:
Engine type: electric, brushless
Turnover: 4370kV
Power: 550W
Resistance: 0.0127Ω
Power consumption: 46A
Diameter: 35.8mm
The length of the body: 25mm
The diameter of the shaft: Φ3.175

Parameters of the speed controller:
Constant current / instantaneous current: 60A / 90A
Resistance: 0.001Ω
Packages: 4-8S NiCd / NiMH or 2-3S LiPo
BEC output: 5V @ 2A
Dimensions: 51.6 x 27.4 x 30mm
Weight: 78g

Parameters of the programming card:
Dimensions: 52.5 x 79.5 x 6.6mm
Weight: 11g
